MS Series

Stationary TMR Mixer, 26 to 36m³

Triple Auger TMR Mixer, Twin Auger TMR Mixer

Watch Video
Stationary TMR Mixer, 26 to 36m³

The MS series stationary TMR mixer is designed for large-scale livestock farms that need high-capacity feed preparation, stable daily output, and efficient centralized ration management. With capacities from 26 to 40 m³, or 918.18 to 1412.58 ft³, this heavy-duty fixed mixing solution supports farms that process large volumes of silage, hay, concentrates, and additives every day.
Depending on production needs, farms can choose twin-auger or triple-auger configurations to match batch size, ingredient structure, and feeding frequency. The motor-driven mixing system cuts and blends feed materials into a consistent total mixed ration, helping reduce ration variation, improve feeding accuracy, and support more organized herd nutrition management.
For operations that need more flexibility in feed scheduling, the system can also serve as a temporary storage tank. This allows farms to prepare feed in advance, balance workflow during peak feeding hours, and keep the feeding process more efficient. Plan a high-capacity fixed mixing setup with UHAND based on your farm scale, ration plan, and feeding center layout.

Contact Us
Specifications
MS Series Stationary Feed Mixer (Twin/Triple Auger TMR Mixer)
Model 3MS-26 3MS-28 3MS-30 3MS-36 2MS-40
Dimensions (L×W×H) (mm) 9450×2250×2650 9450×2250×2780 9450×2250×2940 9450×2250×3320 8650×3180×3600
Weight (kg) 11600 12200 12800 13800 14300
Capacity (m³) 26 28 30 36 40
Motor Power (kW) 90 110 132 160 160
Motor Drive VFD VFD VFD VFD VFD
Number of Augers 3 3 3 3 2
Auger Flighting Thickness (mm) 20 20 20 20 20
Auger Speed (r/min) 30 30 30 30 30
Number of Knives 27 27 27 33 22
Knife Material 65Mn, tungsten carbide coated 65Mn, tungsten carbide coated 65Mn, tungsten carbide coated 65Mn, tungsten carbide coated 65Mn, tungsten carbide coated
Floor Thickness (mm) 20 20 20 20 20
Sidewall Thickness (mm) 10 10 10 10 10
Since 2002, UHAND has been an agricultural equipment manufacturer dedicated to designing and manufacturing TMR feed mixers, automatic livestock feeding systems, manure equipment and other farm machines. Engineered for global dairy and livestock farms, our TMR mixers and automated livestock feeding solutions are built to maximize feed efficiency and lower operational costs.
What truly sets us apart is our focus on practical innovation and real-world reliability. At UHAND, we own and operate a 15.33-hectare (38-acre) commercial dairy farm with approximately 3,000 cattle. This farm serves as our dedicated testing platform, where every piece of our farm equipment is deployed and rigorously proven for daily operations in a live farm environment.
